Compatibility
Compatible with front stiff MTB Rockrider mudguard, sold separately, ref.8579401 (V1) and 8827450 (V2)
or sold as a kit ref. 8579403 (V1) and 8826609 (V2)
Tools and assembly instructions
You'll need a 2,5 mm Allen key.
To mount the bracket, choose the appropriate expansion socket based on the inner diameter of the steerer tube:
- Small 18 mm socket
- Medium 23 mm socket
- Large 33 mm socket
The mudguard can be moved forwards by choosing the most appropriate hole on the bracket.
The mudguard's blade then easily clips onto the bracket.
