Compatibility
You may also need to change the pedal sensor so that these two components are compatible with one another (V2 sensor with V2 bottom bracket).Only compatible with the Mono V3 E-ST100 bottom bracket (check this with one of our technicians)
Technical features
Bottom bracket type: BSC/BSA (English, Euro)
Bottom bracket width: 68 mm
Bearing material: Steel
Type: Square
Axle length: 122 mm
Assembly tips
Bracket tightening torque: 50-70N.m
Crank tightening torque: 35-50N.m
Grease the threads of the bracket for easier installation and removal.
Maintenance advice
Do not use a high-pressure cleaner on the bearings
Need Help?
The technicians at your Decathlon store workshop are available to help you replace your bike's parts. Feel free to ask them for help!
