Main features
640 × 512 resolution with @12 μm thermal sensor
High sensitivity thermal detector
50 mm F1.0 lens with detection range up to 2600 m
High resolution 3840 × 2160 CMOS sensor
xx mm digital lens with digital zoom 5.5x - 22.0x (x4)
0.49-inch OLED display with 1920 x 1080 resolution
Integrated 940 nm IR lamp
Precision laser rangefinder (±1 m) with distance measurement up to 1000 m
Lightweight at 975 g
Optical module
Image sensor: 1.88" progressive-scan CMOS
Max. resolution: 3840 x 2160
Focal length: 60 mm
Aperture: F2.2
Image enhancement: Yes
Min. focus distance : 3 m
Optical zoom: 5.5x - 22.0x（4x)
Field of vision (H × V), Degrees @100 m: 7.3° x 4.1°/12.6 m × 7.2 m @ 100m
Smart IR: Yes
Illuminator wavelength: 940 nm
Night vision range: 350 m
Thermal module
Sensor : VOx uncooled focal plane arrays
Resolution: 640 x 512
Frame rate: 50 hz
No pixel: 12 μm
Spectral band: 8 µm – 14 µm
NETD: < 15 mk (@25°c, f# = 1.0)
Lens (focal length): 50 mm
Aperture: f 1.0
Digital zoom: 1 ×, 2 ×, 4 ×, 8 ×
Magnification: 4.3x-20.0x (4.6x)
Detection range: 2600 m
Min. setting distance 5 m
Focus mode: Manual
Field of view (h × v), degrees/m @100 m: 8.8° × 5.3°/15.4m x 9.3m
Laser rangefinder
Laser safety class: Class 1
Wave length: 905 nm
Max. measurement range: 1000 m
Accuracy of measurement: ± 1 m
Min. measurement distance: 10 m
Screen
DISPLAY: 0.49 inch, OLED, 1920 × 1080
Pallets: Thermal Warm White, Warm Black, Warm Red, Fusion/Optical: Day, Night, Auto
FFC mode FLAT FIELD CORRECTION): Auto, Manual, External correction
Exit pupil: 8 mm
Eye relief: 15 mm
Dioptery: -5 D to +3 D
Brightness adjustment: Yes
Tone adjustment: Cold, warm
Contrast adjustment: Yes
Image pro: Yes
Zoom pro: Yes
System
Built-in memory: 64 GB
Video recording: Yes
Photo recording: Yes
Audio recording: Yes
Standby mode: Yes
PIP: Yes
Hotspot: Yes
Follow the hot point: Yes
GPS: Yes
Digital magnetic compass: Yes
Local album: Yes
Power source
Battery type: replaceable and rechargeable Li-ion battery
Battery operating time: 10.5 hours continuous operation with hotspot function deactivated (@25°C)
TYPE-C POWER SUPPLY: Yes
General
Protection level: IP67
Dimensions: 142.9 mm × 79.7 mm × 230.5 mm
Weight: 975 g with battery
Working temperature: -30°C to 55°C
Interpupillary adjustment range/60 mm to 74 mm
Mounting adaptor: 1/4’’-20 UNC
