LOWRANCE

EAGLE 9 TripleShot fishing sonar

Designed for demanding anglers, the EAGLE 9 TripleShot™ Lowrance has an accurate sonar with triple CHIRP, DownScan & SideScan beams for ultra-smooth observation

The EAGLE 9 TripleShot™ Lowrance combines CHIRP, DownScan and SideScan technologies with a high-resolution 9” screen for clear, comprehensive river bed and fish observations.

ID 9027318

€839.99
VAT included

  • Pick up at Decathlon

    Loading...

  • Pick up near you

    Loading...

  • Home Delivery

    Loading...

  • Features

    Design benefits

    • precision

      TripleShot sonar for a panoramic view of structures, river beds and fish

    Design details

    DISPLAY EAGLE 9 TripleShot Lowrance

    Size of the screen: 9” IPS
    Screen resolution: 800x480
    Screen brightness: >1,200 nits
    Touch screen
    Multitouch
    Keyboard
    Pages, waypoint, zoom, power, (1) user-programmable quick-access keys
    Viewing angles: 50° top 60° bottom 70° left/right

    SONAR 1 EAGLE 9 TripleShot Lowrance

    Compatibility of the sonar

    Integrated:
    CHIRP, Broadband, Active Imaging™ HD DownScan*, Active Imaging™ HD SideScan*, Active Imaging™ DownScan, Active Imaging™ SideScan
    *requires S3100 module

    Compatible with:
    ActiveTarget® 2, ActiveTarget®, S3100, SonarHub®, StructureScan®, StructureScan®HD, StructureScan®3D, LiveSight (requires PSI-1 module)

    SONAR 2 EAGLE 9 TripleShot Lowrance

    sonar frequencies

    CHIRP
    High CHIRP
    Medium CHIRP
    Low CHIRP
    (depending on the transducer)

    Broadband
    50 kHz
    83 kHz
    200 kHz
    (depending on the Broadband transducer)

    Active Imaging
    800 kHz
    455 kHz

    Active Imaging HD (Via additional S3100 module)
    DownScan:
    700 kHz CHIRP
    1200 kHz CHIRP

    SideScan:
    455 kHz CHIRP
    1075 kHz CHIRP

    MULTIFUNCTION SCREEN 1 EAGLE 9 TripleShot Lowrance

    AIS
    AIS chart overlay.
    Target vessel details.
    Autopilot
    Outboard Pilot
    Ghost® Trolling Motor
    Recon™ Trolling Motor
    MotorGuide Xi5/Xi3 Trolling Motor (requires Motorguide PinPoint Gateway)

    MULTIFUNCTION SCREEN 2 EAGLE 9 TripleShot Lowrance

    Cartography included: World basemap

    Cartography
    C-MAP® REVEAL™
    C-MAP® DISCOVER™
    C-MAP® Genesis
    Navionics (Gold, NAV+ Platinum+)
    Lowrance Regional Mapping Partners

    GPS
    10 Hz Internal high-sensitivity WAAS + EGNOS + MSAS

    Waypoints, routes, traces
    3000 Waypoints
    100 Routes
    100 Trails with up to 10,000 points per trail

    INTERFACE AND CONNECTIVITY EAGLE 9 TripleShot Lowrance

    NMEA 2000®
    1x Micro-C

    Ports Ethernet
    1 x 100Mbit

    Stockage sur carte SD1 micro SD card up to 32GB
    Wi-Fi®

    Internal 802.11b/g/n
    Bluetooth®

    Bluetooth® 4.0 with support for Bluetooth® classic

    ELECTRICAL EAGLE 9 TripleShot Lowrance

    Supply voltage
    12 VDC (10.8-17 VDC)

    Max. power consumption
    2.0 A @ 13 VDC with backlight on full

    Recommended fuse rating
    3 A

    PHYSICAL EAGLE 9 TripleShot Lowrance

    Weight: 1.2 kg (2.7 lbs)

    Type of rig
    Gimbal Bracket or Dash Flush Mount

  • Usage & care

    Warranty

    2 Years
