Technical features
Can be installed on a frame with a 68mm Euro-type square-taper bottom bracket (with English threading).
Bottom bracket width: 68mm
Length: 115 mm.
Also available in 110mm, 113mm, 118mm and 122.5mm
Bearing material: Steel
Type: Square
Bottom bracket type: BSC/BSA (English, Euro)
Weight: 332 g
Assembly tips
Bracket tightening torque: 50-70N.m
Crank tightening torque: 35-50N.m
Grease the threads of the bracket for easier installation and removal.
Care advice
Do not use a high-pressure cleaner on the bearings
NEED HELP?
The technicians at your Decathlon store workshop are available to help you replace the parts of your bike. Feel free to ask them for help!
