HIKMICRO

Thermal imaging binoculars Habrok 4K HE25LN 5.5-22X60

4.9 out of 5 stars From 17 reviews
17 reviews

Designed to cope with any situation, day or night, thanks to two sensors - optical and thermal!

First there’s an optical sensor with a zoom of 5.5 to 22, and there is also a 256 × 192 thermal sensor coupled to a rangefinder with a 1000 metre range. All in all, a high-performance combo.

ID 8938422

€1,199.99
VAT included

  • Pick up at Decathlon

    Loading...

  • Pick up near you

    Loading...

  • Home Delivery

    Loading...

Design benefits

  • autonomy

    Replaceable battery, up to 8 hours continuous operation

  • magnification

    In-image digital zoom from 5.5x to 22x in optical mode

  • range

    Maximum detection range of 1,200 metres

  • image quality

    256 × 192 thermal sensor connected to a 1920 x 1080 OLED display

  • distance

    A laser rangefinder with a range of 1000 metres

  • field of vision

    Focal length: 25 mm Field of vision at 100 m: 7.0° × 5.3° / 12.2 m × 9.3 m

  • weight

    795 g; dimensions: 138 mm × 68.2 mm × 223 mm

  • Features

    Design details

    Main features

    256 × 192 resolution with @12 μm thermal sensor
    High sensitivity thermal detector NETD < 35 mK (@25°C, F# = 1.0)
    25 mm F1.0 lens with detection range up to 1200 m
    High resolution 3840 × 2160 4K CMOS sensor
    60 mm F2.2 digital lens with 5.5x to 22x digital zoom
    0.49-inch OLED display with 1920 x 1080 resolution
    Integrated 940 nm IR lamp
    Precision laser rangefinder (±1 m) with distance measurement up to 1000 m
    Lightweight at 795 g

    Optical module

    Image sensor: 1.88" progressive-scan CMOS
    Max. resolution: 3840 × 2160
    Focal length: 60 mm
    Aperture: F2.2
    Image enhancement: Yes
    Min. focus distance : 3 m
    Magnification: 5.5 - 22.0 (x4 zoom)
    Field of view (h × v), degrees/m @100 m: 6.9° × 4.1° (h × v)/ 12.0 m × 7.2 m @ 100m
    Smart IR: Yes
    Illuminator wavelength: 940 nm
    Night vision range: 350 m

    Thermal module

    Sensor : VOx uncooled focal plane arrays
    Resolution: 256 × 192
    Frame rate: 50 hz
    No pixel: 12 μm
    Spectral band: 8 µm – 14 µm
    NETD: < 35 mk (@25°c, f# = 1.0)
    Lens (focal length): 25 mm
    Aperture: f 1.0
    Digital zoom: 1 ×, 2 ×, 4 ×
    Magnification: 4.3 - 17.2 (x4 zoom)
    Detection range: 1200 m
    Min. setting distance 3 m
    Focus mode: Manual
    Field of view (h × v), degrees/m @100 m: 7.0° × 5.3° (h × v)/ 12.2 m × 9.3 m @ 100m

    Laser rangefinder

    Laser safety class: Class 1
    Wave length: 905 nm
    Max. measurement range: 1000 m
    Accuracy of measurement: ± 1 m
    Min. measurement distance: 10 m

    Screen

    DISPLAY: 0.49 inch, OLED, 1920 × 1080
    Pallets: Thermal Warm White, Warm Black, Warm Red, Fusion / Optical: Day, Night, Auto
    FFC mode FLAT FIELD CORRECTION): Auto, Manual, External correction
    Exit pupil: 8 mm
    Eye relief: 15 mm
    Dioptery: -5 D to +3 D
    Brightness adjustment: Yes
    Tone adjustment: Cold, warm
    Contrast adjustment: Yes
    Image pro: Yes
    Zoom pro: Yes

    System

    Built-in memory: 64 GB
    Video recording: Yes
    Photo recording: Yes
    Audio recording: Yes
    Standby mode: Yes
    PIP: Yes
    Hotspot: Yes
    Follow the hot point: Yes
    GPS: Yes
    Digital magnetic compass: Yes
    Local album: Yes

    Power source

    Battery type: replaceable and rechargeable Li-ion battery
    Battery operating time: 8 hours continuous operation with hotspot function deactivated (@25°C)
    TYPE-C POWER SUPPLY: Yes

    General

    Protection level: IP67
    Dimensions: 138 mm × 68.2 mm × 223 mm
    Weight: 795 g without battery
    Working temperature: -30°C to 55°C
    Interpupillary adjustment range / 60 mm to 70 mm
    Mounting adaptor: 1/4’’-20 UNC

  • Usage & care

    Warranty

    2 Years
