ROCKRIDER

29" Touring Mountain Bike Expl 500 - Red

Designed for mountain bike rides all year round, from 2 to 3 hours long.

Enjoy greater comfort and responsiveness on your 2- to 3-hour mountain bike rides all year round. This model features 29" wheels (27.5" in size S), a single chainring and hydraulic disc brakes.

ID 8920257

VAT included

Color: Orange

Pick up at Decathlon

Loading...
Pick up near you

Loading...
Home Delivery

Loading...

Design benefits

brake control

Manage your trajectory: hydraulic disc brakes, and wide tyres and handlebar.
ease of use

Change speed with one hand, without even thinking: SINGLE CHAINRING DRIVETRAIN
lifetime warranty

ROCKRIDER offers a lifetime warranty on the frame, handlebars and stem.
efficiency

Lightweight alu frame, 29" wheels (27.5" in S), 9-speed single chainring
ease of handling

Enjoy an upright position, adjustable stem, 100mm suspension and hammock saddle.

Features

Design details

In a nutshell

Weight: 14.85 kg in size M (without pedals)
Frame material: Aluminium
Type: Hardtail
Wheel size: 29" (M / L / XL), 27.5" (S)
Fork travel: 100 mm
Drivetrain: 1x9
Brakes: Hydraulic
Seatpost: Steel
Frame, stem and handlebar warranty: lifetime

Weight

S: 14.5 kg
M: 14.85 kg
L: 14.95 kg
XL: 15.05 kg

Net weight without pedals

Frame

Composition: 6061 aluminium
135 mm x 9 mm rear axle
QR spindle
73 mm threaded bottom bracket (BSA)
Protective cover for housing
27.2 mm seat tube
Straight head tube
2 bottle cage mounts (1 on size S) / Pannier rack mounts

Drivetrain

30 T single chainring (compatible with 32 T)
175 mm crank
"Square taper" bottom bracket

Microshift Advent
9-speed shifter and rear derailleur
11-42 cassette

KMC Z9 chain

Suspension

Suntour XCM fork
Coil spring
100 mm travel
Stanchion diameter: 30 mm
QR axle
9 x 100 mm

Wheels

29" (M / L / XL), 27.5" (S)
Tubeless ready rims, Presta valve
23 mm inner width (28 mm outer)
32 spokes (M / L / XL), 28 spokes (S)
6-bolt disc
Shimano/Sram freehub

Brakes

Hydraulic disc brakes
Tektro TK-M276
Number of pistons: 2
Front disc: 160 mm
Rear disc: 160 mm
Adjustable reach: Yes

Riding position

Handlebar: Rockrider Sport
Material: Aluminium
Width: 740 mm (M / L / XL), 700 mm (S)

Stem: Rockrider
Material: Aluminium
Size: 60 mm
4 adjustment increments: +0 mm, +5 mm, +20 mm, +25 mm

Grips: Rockrider SPORT

/ Seat post

Rockrider Ergofit saddle

Rockrider Sport seat post
Material: Steel
Diameter: 27.2 mm
Length: 350 mm (S / M), 400 mm (L), 450 mm (XL)

Tyre

Rockrider All Conditions
29"x2.2" (M / L / XL), 27.5"x2.2" (S)
Carcass: 60 TPI

Pedals

Rockrider 520 Grip resin flat pedals

ACCESSORIES INCLUDED

Your mountain bike comes with a bell, lighting, wheel reflectors, and pedals.
Usage & care

Instructions
Download

Warranty

2 Years

Care Instructions

Storage tips

After washing, pass a dry cloth to remove all traces of moisture. Lubricate the drive train and store the bike in a cool, dry place away from corrosive products and salty air.

Usage precautions

Not suitable for All Mountain, Enduro and BMX mountain biking
Specifications

Composition

Bike frame: 100.0% Aluminium
Testing

Test product

Ask your local Decathlon store about testing before purchase.

Agree by

Our engineers always have real riders test all our products in real conditions. These tests round out our lab tests and let us validate all our products before they hit store shelves.

Parts guarantee

Lifetime (frame, stem, handlebars). Availability of spare parts: 2 years.
