Technical specifications
Can be mounted on a frame with a 68 mm Euro-type square-taper bottom bracket (with English threading).
Bottom bracket width: 68mm
Length: 122.5 mm.
Also available in 110mm, 113mm, 115mm, 118mm.
Material: Steel
Type: Square
Bottom bracket type: BSC/BSA (English, Euro)
Weight: 345 g
Assembly tips
Bottom bracket tightening torque: 50-70N.m
Crank tightening torque: 35-50N.m
Remember to grease the bottom bracket thread to facilitate screwing and unscrewing.
Maintenance tips
Do not use a high-pressure cleaner on bearings
